首页产品中心输送带 Bishamon手托盘卡车类型无人运输车辆均匀负载1000kg叉长1070 x宽度153 x间距294mm总长度1712mm

Bishamon手托盘卡车类型无人运输车辆均匀负载1000kg叉长1070 x宽度153 x间距294mm总长度1712mm

品牌： sugiyasu

型号： ABM10-60M

分类：输送带

产品简介

产品型号: ABM10-60M产品品牌: sugiyasu 特征可以直接将直接位置的托盘被直接挖出并无人运输 […]

联系我们

咨询电话

13341245831，18863977737

微信号

Ahy__w

扫码添加微信

产品详细信息

产品型号: ABM10-60M

产品品牌: sugiyasu

特征

可以直接将直接位置的托盘被直接挖出并无人运输。
您可以简单地将磁带粘贴在地板上来自动驾驶。
也可以通过切换到手动驾驶来用作电动车辆。
负载宽度检测杆传感器是可选的。

功能结束

目的

用于运输托盘的行李和其他重物。
用于长距离运输和移动。
在各种工厂，物流中心，仓库等中运输重型物品，例如托盘和机械。

使用端

注意

将在卡车上交付。
请注意，这是一个繁重的物品。
将收取单独的票价。
根据形状的不同，某些托盘可能无法使用。
选择佳型号之前，请检查大小和其他详细信息。

注意结束

产品规格

规格和标准	Battery-powered Continuous driving: Approximately 3 hours (when driving automatically) Induction method: Magnetic tape Fork outer width 600mm, inner width 294mm Setting station: Up to 3 locations (optional) Fork point: Up to 9 locations (optional) Road surface unevenness: Up to 9 locations (optional) Road surface unevenness: Up to 5mm or less Safety device (standard): Emergency stop button, obstacle contact bumper, overcurrent detection, derailment detection, handle tilt detection, battery alarm, patrol light Uniform load (kg): 1000 Fork height (mm) Minimum: 80 Fork height (mm) Maximum: 200 Fork length: 1070 Fork width: 153 Fork (mm) spacing: 294 Overall width (mm): 650 Overall height (mm): 1196 Overall length (mm): 1712 Lifting method: Manual type Running method: Battery type (manual) Backward/backward (automatic) One-way Charging time: Approximately 8 hours Power supply (V): Single phase 100V Continuous driving time: Approximately 5 hours Steering wheel: Urethane wheels Road车轮：尿烷车轮电源：单相100V制动方法：电磁制动器，再生制动器电池：24V/30AH/5HR x 2（屏蔽）充电器：单独类型（可选）叉（mm）长度：1070 p>>
材料	主体：钢主体表面处理：三聚氰胺烘焙油漆车轮：尿电烷手柄部分：树脂

规格和标准

Battery-powered
Continuous driving: Approximately 3 hours (when driving automatically)
Induction method: Magnetic tape
Fork outer width 600mm, inner width 294mm
Setting station: Up to 3 locations (optional)
Fork point: Up to 9 locations (optional)
Road surface unevenness: Up to 9 locations (optional)
Road surface unevenness: Up to 5mm or less
Safety device (standard): Emergency stop button, obstacle contact bumper, overcurrent detection, derailment detection, handle tilt detection, battery alarm, patrol light
Uniform load (kg): 1000
Fork height (mm) Minimum: 80
Fork height (mm) Maximum: 200
Fork length: 1070
Fork width: 153
Fork (mm) spacing: 294 Overall width (mm): 650 Overall height (mm): 1196 Overall length (mm): 1712 Lifting method: Manual type Running method: Battery type (manual) Backward/backward (automatic) One-way Charging time: Approximately 8 hours Power supply (V): Single phase 100V Continuous driving time: Approximately 5 hours Steering wheel: Urethane wheels Road车轮：尿烷车轮电源：单相100V制动方法：电磁制动器，再生制动器电池：24V/30AH/5HR x 2（屏蔽）充电器：单独类型（可选）叉（mm）长度：1070 p>>

材料

主体：钢
主体表面处理：三聚氰胺烘焙油漆
车轮：尿电烷
手柄部分：树脂
