首页产品中心物理和化学用品 Yamato [每次报价]空气常数温度恒定温度恒定（吹烤箱）DKV610

Yamato [每次报价]空气常数温度恒定温度恒定（吹烤箱）DKV610

品牌：大和科学技术

型号： DKV610

分类：物理和化学用品

产品简介

产品型号: DKV610产品品牌: 大和科学技术特征易于使用且高度可见的颜色LCD控制器。带有点击功能的 […]

联系我们

咨询电话

13341246192

微信号

ahy_gl

扫码添加微信

产品详细信息

产品型号: DKV610

产品品牌: 大和科学技术

特征

易于使用且高度可见的颜色LCD控制器。
带有点击功能的门铰链可防止由于倾斜而关闭门，从而使您可以安全地插入并取出样品，而不必担心烧伤或接触。
独立的过高预防装置标准配备了数字类型。
与DKM和DKN系列（没有观察窗口的型号）相比，功耗已减少约15-25％。
提供多种选择，包括看台，堆叠硬件，外部通信和记录器。

功能结束

目的

用于广泛的应用，包括干燥和温度测试。

使用端

注意

请注意，如果已验证的产品与用户的实际用户不同，则保修可能不包括保修。

注意结束

产品规格

规格和标准	Ambient temperature range: 5 to 35°C Temperature control range: Room temperature +10°C to 270°C Temperature fluctuation: ±0.5°C (at 270°C) Temperature gradient: 9°C (at 270°C) Temperature rise speed: 2.8°C/min Temperature rise time: Approximately 85 minutes Operating functions: Fixed value operation, Quick auto stop operation/Auto stop operation/Auto start operation/Program auto start operation (time and time setting), Program operation (time setting) Additional functions: Calibration offset function/Power failure recovery mode selection function/Timer weight function/Security management function/Temperature up and down alarm function/Fan OFF delay function/Power failure alarm/External communication terminal (RS-485)/Temperature output terminal (4-20mA)/Time-up output terminal/An abnormal output terminal/Recordmeter terminal/Program preview function/Operation trench Function Power supply (V): Single-phase AC200 Capacity (L): 150 Main body dimensions (mm) Width: 730 Main body dimensions (mm) Depth: 685 Main body dimensions (mm) Height: 880 Effective internal dimensions (mm) Width: 600 Effective internal dimensions (mm) Depth: 500 Effective internal dimensions (mm) Height: 500 Operating temperature range (℃): 5 to 35 Safety device: Self-diagnosis Functions (automatic over-rise prevention, temperature sensor abnormality, SSR short circuit, heater disconnection, fan abnormality, clock element abnormality, main relay abnormality,记忆异常，内部通信异常） /独立预防设备 /门开关（门警报） /泄漏断路器温度调节范围（℃）：室温 +10℃至270方法：架子的强制空气循环数量 /螺距数量：13层 / 30mm货架负载能力：15kg / expling Position：15kg / shew load Posity：30kg / expling Posity：30kg < / p < / p> < / p> < / p> < / p> < / p>> < / p>
材料	-

规格和标准

Ambient temperature range: 5 to 35°C
Temperature control range: Room temperature +10°C to 270°C
Temperature fluctuation: ±0.5°C (at 270°C)
Temperature gradient: 9°C (at 270°C)
Temperature rise speed: 2.8°C/min
Temperature rise time: Approximately 85 minutes
Operating functions: Fixed value operation, Quick auto stop operation/Auto stop operation/Auto start operation/Program auto start operation (time and time setting), Program operation (time setting)
Additional functions: Calibration offset function/Power failure recovery mode selection function/Timer weight function/Security management function/Temperature up and down alarm function/Fan OFF delay function/Power failure alarm/External communication terminal (RS-485)/Temperature output terminal (4-20mA)/Time-up output terminal/An abnormal output terminal/Recordmeter terminal/Program preview function/Operation trench Function
Power supply (V): Single-phase AC200
Capacity (L): 150
Main body dimensions (mm) Width: 730
Main body dimensions (mm) Depth: 685
Main body dimensions (mm) Height: 880
Effective internal dimensions (mm) Width: 600
Effective internal dimensions (mm) Depth: 500
Effective internal dimensions (mm) Height: 500
Operating temperature range (℃): 5 to 35
Safety device: Self-diagnosis Functions (automatic over-rise prevention, temperature sensor abnormality, SSR short circuit, heater disconnection, fan abnormality, clock element abnormality, main relay abnormality,记忆异常，内部通信异常） /独立预防设备 /门开关（门警报） /泄漏断路器温度调节范围（℃）：室温 +10℃至270方法：架子的强制空气循环数量 /螺距数量：13层 / 30mm货架负载能力：15kg / expling Position：15kg / shew load Posity：30kg / expling Posity：30kg >
